Flight Clave 8 Plus Autoclave

The Clave8+ chamber type autoclave is a Class S steam sterilizer that utilizes a state-of-the-art steam pulsing technology. The Clave8+ uses a pressure displacement technology that allows a more complete removal of air inside the chamber before the sterilization cycle begins . In addition, with the steam injection pressure pulsing technology it reduces maintenance, improves sterilization effectiveness and increases speed of the sterilization process.

The Clave8+ uses the highest quality components and each unit is stress tested to ensure the quality and reliability of the machine. The Clave8+ is compact and efficient sterilizer is suitable for any dental, veterinary, podiatry, chiropodist, tattoo, medical and beauty office.

As the name suggests this is the largest chamber autoclave offered by Flight Dental Systems at 8L in capacity.

The Clave8+ also has an air assisted drying technology which integrates a compressor for faster drying.

• Easily accessible and easy to fill.
• Water Level Sensor
• Capacity to run 5-6 Cycles Before Adding water

• Fast Sterilization Cycles – 12 Minutes Unwrapped Flash Cycle

• 5 Programmed Sterilizations Cycles: Flash/Unwrapped, Wrapped, Liquid, Textile, Prions

• Independent Steam Generator for positive pressure displacement dynamic pulsating steam injection

• Double Door Protection System – Prevents door from opening during Cycles (Provides Closed Door Drying)

• HEPA Filter to ensure clean air into chamber



  Frequency	Maintenance Required
  Daily	Clean Door Seal   Clean the External Surface
  Weekly	Clean Distilled Water Reservoir   Clean Sterilization Chamber
  Monthly	Clean Filter inside Chamber and Tank
  Every 3/6 Months	Replace Door Seal
  Every Year	Replace Silicone Tubing, filters and door Seal
  Every 2 Years	Replace Battery on Main PCB that Controls Timer



  Comparison with Enbio S







  	Flight Clave8+	Enbio S
  Capacity	8L	2.7L
  Load Size	3.3lbs – Wrapped	1.1lbs – Wrapped
  Cycle Time	12min Unwrapped	7min Unwrapped
  Internal Memory	10,000 Cycles	20 Cycles
  Printer	Built in (Included)	None
  Datalogger	USB	USB
  Warranty	2 Year	1 Year
  Availability	Canada and USA	Canada and USA
  Trays	2/3	1
  Clean Water Reservoir	Internal Tank	External Bottle *(Bottle Not Included)
  Waste Water	Internal Tank and Auto Drain	External Bottle *(Bottle Not Included)
  Bowie Dick Test	Not Required	Required Each Day
  Class of Sterilizer	Class S	Class B

  Specifications







  Model	Voltage	Rated Power	Chamber Size	Weight
  Clave8+	110V	1600W	Φ6.7″X 12.6″ (8L)	82 lbs



• Fast Sterilization Cycles Unwrapped: 4min, Wrapped: 10 min, Rubber/Textiles: 10min
• Larger Chamber compared to Statim with Similar Sterilization Time
• 2 Year Parts Warranty
